The VAL Audio X15CXA is a next-generation powered coaxial stage monitor designed to meet the demands of today’s professional performers and sound engineers. At its core is a precision-engineered coaxial transducer system, where a 15” low-frequency driver and a 2” high-frequency compression driver share a common axis. This alignment ensures phase-accurate sound reproduction, seamless frequency integration, and consistent coverage across the entire listening area — a critical advantage for stage monitoring where clarity and uniformity are paramount.
Driven by a high-efficiency Class-D amplifier delivering 1200W Peak / 600W RMS, the X15CXA combines raw power with refined control. The integrated DSP offers four presets, EQ-high/mid/low control, delay, and high-pass filtering, allowing the monitor to be adapted instantly for vocals, instruments, or full-range stage mixes. A built-in two-channel mixer with mic/line inputs, AUX and XLR output further enhances flexibility, making the X15CXA equally at home in touring rigs, corporate events or fixed installations.
Designed with both performance and practicality in mind, the X15CA features a low-profile wedge enclosure that keeps sightlines clear while ensuring optimal monitoring angles. Multiple handles, a rugged protective grille, and a pole-mount option add versatility and durability, making it a reliable workhorse for the most demanding live sound environments.
- Coaxial Speaker Design – 15” woofer with 2” HF compression driver in coaxial alignment for natural, phase-accurate sound
- High-Powered Amplification – Class-D bi-amplified system delivering 1200W Peak / 600W RMS power output
- Integrated DSP – Multi-function DSP with 4 presets, EQ, delay, and high-pass filter
- Flexible Connectivity – Two-channel mixer with mic/line input, ¼” combo jack, 3.5mm AUX and XLR mix output
- Optimized Frequency Response – Wide, balanced coverage ensuring clarity on any stage
- Portable & Versatile – Low-profile wedge design with pole-mount option and multiple carry handles
- Durable Construction – Rugged cabinet, protective grille, and professional-grade components for touring reliability
The VAL Audio X15CA is a versatile stage monitor designed for demanding professional use. Its powerful coaxial design, DSP control, and rugged build make it ideal for:
- Live stage monitoring for vocalists and musicians
- Touring and rental systems requiring durability and flexibility
- DJ and club use with high output and clarity
- Corporate events and presentations where speech intelligibility is critical
- Houses of worship and fixed installations needing reliable, full-range monitoring
| System Type | Powered Coaxial Stage Monitor |
| Frequency Response | 45Hz – 20kHz |
| Maximum SPL | 133dB |
| Sensitivity | 99dB |
| Coverage (H x V) | 90° x 90° |
| Power Amplifier | Class D, Bi-amp 1200W Peak / 600W RMS power output |
| Integrated DSP | Master level control Fixed 4 Presets EQ – High,Mid,Low Delay High-pass |
| LCD Display | Integrated with brightness control |
| Low Frequency Driver | 1 x 15’’ (3” VC) |
| High Frequency Driver | 2” compression driver (coaxially mounted) |
| Connectors | 2 x XLR/TRS combo Mic/Line Inputs 1 x 3.5mm stereo Input 1 x XLR Mix Out |
| AC Power Input | PowerCON® Input and Thru – 230VAC, 50Hz |
| Power Consumption | Idle: 20W, Full Power: 340W |
| Enclosure | Low-profile wedge, pole-mount capable, high quality wooden cabinet |
| Carry Handles | Yes |
| Monitor Wedge | Yes |
| Grille | Steel grille with acoustic foam |
| Finish | Polyurea paint |
| Colour | Black |
| Dimensions (HxWxD) | 390 x 535 x 490 mm |
| Net Weight | 22.65 Kg |
