KEY FEATURES
- High quality high definition two way coaxial ceiling speaker
- High power handling featuring high performance crossover
- High quality black kevlar coneFerrofluid cooled silk dome tweeter with swivel mount for high frequency directivity
- Magnetic grille and dog ears for effortless ceiling mounting
- Architects delight complete flush mount,no bezel visible only metallic grille visible
- All high end and audiophile grade components used for superior sound quality
- LMT version available
- Pearl White colour
APPLICATIONS
The iComm CS6.2 loudspeaker is a 6.5’’ two way coaxial ceiling speaker suitable for
- Restaurants, offices, auditoriums, gymnasiums, conference rooms, AV rooms, BGM applications
- Music, Hi-Fi and home theater applications
- Contractors, custom installers & retail stores
TECHNICAL DATA
Power Handling (AES Standard) | 50W RMS / 100W Program / 200W Peak |
Nominal Impedance | 8 ohms |
Frequency Response (-6db half space) | 50Hz – 20KHz |
Average Sensitivity | 89dB/W/m |
Calculated Max SPL | 106dB Continuous / 109dB Program / 112dB Peak |
Low Frequency Driver | 6.5’’ Kevlar cone woofer with rubber surround |
High Frequency Driver | 1’’ Ferro Fluid cooled silk dome |
Input Connectors | Spring Push Loaded |
LMT | Optional Extra |
Cabinet | ABS with Magnetic Grille |
Size (WxHxD) | 250 x 98mm |
Cutout Size | 209mm |
Mounting Depth | 95mm |
Net weight | 1.75Kg |
