The SW118HP is a high power, subwoofer designed for both indoor/outdoor venues and touring applications requiring low frequency reproduction. SW118HP can be used singularly or in multiples. The SW118HP can be flown using M10 inserts. Ground stacking is also possi- ble with any VAL Point source QX, VX and ZX systems.
Using our proprietary 18” die-cast aluminium chassis high excursion driver in a direct radiating bass reflex design , this cabinet has a frequency response of 34Hz to 1200Hz (-6 dB) at a high 135 dB SPL (peak).
The robust enclosure has a kick proof front grill with internal foam, hardwearing touring grade textured waterborne Black paint finish and one large heavy duty integrated handles on each side achieving a high class look suitable for any application.
Integrated feet are located on underside of the enclo-sure for securing in multiple ground stack.
The SW118HP features a top hat pole mount adapter in order to enable pole mounting tops. It also features multiple M10 inserts enabling the SW118HP to be flown where necessary.
The rear cast aluminium connection plate has Two 4 pin speakON® connectors fitted as standard. The spea- kON® connectors are wired on pins +1-1, with pass through of pins +2-2.
- High output direct radiating single 18″ Subwoofer
- Deep and warm bass down to 34 Hz
- Compact vented enclosure suitable for trendy installations
- 1000W RMS power handling
- 135dB Peak SPL
- Premium European 18″ LF driver with high excursion capacity for extended low frequency response
- High strength fiber-reinforced cone
- Advanced thermal management via internal heatsink on die-caste chassis of driver
- Touring grade textured waterborne Black,scratch resistant coating
- Top hat provision for pole mounting top
- Carry handles on the sides for easy transport
Design | 1 x 18” Subwoofer, Bass Reflex/ Direct Radiating Subwoofer |
Impedance | 4 ohm |
Power Handling (AES) | 1000 Watts (continuous) |
Max. Power Handling (AES) | 2000 Watts (program) 4000 Watts (peak) |
Sensitivity 1W / 1m | 99 dB |
Max. SPL | 129 dB cont 135 dB peak |
Usable Frequency Range (-6 dB) | 34 Hz – 1200 Hz |
Dispersion | Omni |
Recomended Amplification | 1000 – 2000 Watts |
System Controller | VAL DSP Solutions |
Speaker Cables | Min – 2 x 4 mm² Preferred – 2 x 6 mm² |
Components | 1 x 18” Low Frequency Driver |
Crossover | Active – LPF – 80 – 120 Hz HPF – 35 Hz |
Connectors | 1 x 4 pole speakON® connectors |
Dimensions (H x W x D mm) | 543.5 x 635 x 609.6 |
Weight (kg) | 45.4 |
Shipping Weight (kg) | 51.40 (1 cabinet per carton) |
Colour | Black |
Rigging | M10 inserts |
Fitted as Standard | 16 x M10 inserts, Top hat, large handles |
Additional Descriptive Data | Medium density fiberboard construction, with durable scratch resistant black textured paint finish, kick-proof steel grill and black foam with VAL logo |
