KEY FEATURES
- High quality two way surface mount speaker for indoor / outdoor applications
- Only high quality components used
- 5.25” Polypropylene LF driver with rubber surround
- 0.5”’ Mylar tweeter for smooth HF response
- In-built LMT for 100V/8 ohm operation, multiple tapping
- Innovative design with easy mounting adjustable swivel bracket for horizontal and vertical mounting on wall / ceiling
- High quality weatherised ABS cabinet with rust proof grille for outdoor usage
- Complete weather proof outdoor capable designed to meet IP55 standards
- Rear protective cover to prevent water ingress
- Available in Black colour
APPLICATIONS
The iComm SMS52T is two way multipurpose monitor speaker suitable for
- Indoor applications: Restaurants, offices, museums, home theater, auditoriums, gymnasiums, F&B establishments
- Outdoor applications: Atriums, pool side, patios, backyards and more
- Contractors, custom installers & retail stores
TECHNICAL DATA
Power Handling (AES Standard) | 40W RMS / 80W Program / 160W Peak |
Nominal Impedance | 8 ohms |
Frequency Response (-10db) | 70Hz – 20KHz |
Average Sensitivity | 88dB/W/m |
Calculated Max SPL | 104dB Continuous / 107dB Program / 110dB Peak |
Low Frequency Driver | 5.25’’ Polypropylene woofer with rubber surround |
High Frequency Driver | 0.5’’ Mylar tweeter |
Input Connectors | Binding post push terminals |
100V Connectivity | 2W, 4W, 8W & 16W selectable via rotary switch |
Cabinet | High Quality, ABS with rust proof aluminum grille |
Colour | Black |
Wall mount bracket | Included, heavy duty swivel U bracket for horizontal and vertical mounting |
Outdoor Capable | Weatherized designed to meet IP55 standards |
Size (WxHxD) | 160 x 260 x 155mm |
Net weight | 2.70Kg |
