KEY FEATURES
- High quality two way surface mount speaker for indoor / outdoor applications
- Only high quality components used
- High power handling 500W peak
- 8” Polypropylene LF driver with rubber surround
- 1” Silk dome tweeter for smooth HF response
- In-built LMT for 100V/8 ohm operation, multiple tapping
- Innovative design with easy mounting adjustable swivel bracket for horizontal and vertical mounting on wall / ceiling
- High quality weatherised ABS cabinet with rust proof grille for outdoor usage
- Complete weather proof outdoor capable designed to meet IP55 standards
- Rear protective cover to prevent water ingress
- Available in Black colour
APPLICATIONS
The iComm CB82T is two way multipurpose
monitor speaker suitable for
- Indoor applications: Restaurants, offices, museums, home theater, auditoriums, gymnasiums, F&B establishments
- Outdoor applications: Atriums, pool side, patios, backyards and more
- Contractors, custom installers & retail stores
TECHNICAL DATA
| Power Handling (AES Standard) | 125W RMS / 250W Program / 500W Peak |
| Nominal Impedance | 8 ohms |
| Frequency Response (-6db Half space) | 45Hz – 20KHz |
| Average Sensitivity | 90dB/W/m |
| Calculated Max SPL | 111dB Continuous / 114dB Program / 117dB Peak |
| Low Frequency Driver | 8” Polypropylene woofer with rubber surround |
| High Frequency Driver | 1” tweeter |
| Input Connectors | Binding post push terminals |
| 100V Connectivity | 10W, 20W, 40W & 80W selectable via rotary switch |
| Cabinet | High Quality, ABS with rust proof aluminum grille |
| Colour | Black |
| Wall mount bracket | Included, heavy duty swivel U bracket for horizontal and vertical mounting |
| Outdoor Capable | Weatherized designed to meet IP55 standards |
| Size (WxHxD) | 240 x 380 x 230mm |
| Net weight | 4.95Kg |
